Lembaran data: 1.PJ-059B.pdf ...

Helaian data
PJ-059B.pdf

Reka bentuk/spesifikasi PCN
Multiple Devices Plating 19/Sep/2014.pdf

HTML Datasheet
PJ-059B.pdf

Status RoHS: Mematuhi ROHS3

~~Bandingkan~~

Pensijilan kami

Dalam stok: 39158

Harga seunit: $0.795
jumlah kecil: $0.00

Mahukan harga yang lebih baik?
Tambah ke Cart dan Hantar RFQ Sekarang, kami akan menghubungi anda dengan segera.

Kuantiti	Harga seunit	Ext.Harga
1+	$0.795	$0.80
280+	$0.308	$86.24
560+	$0.297	$166.32
1120+	$0.292	$327.04

Harga di atas tidak termasuk cukai dan kadar pengangkutan, yang akan dikira pada halaman pesanan.

PILIHAN EXPRESS

Kaedah pembayaran

Pensijilan kami

Spesifikasi

Spesifikasi teknologi PJ-059B
Spesifikasi Teknikal CUI Devices - PJ-059B, Atribut, Parameter dan Bahagian dengan Spesifikasi Sama dengan CUI Devices - PJ-059B

Atribut produk	Nilai atribut
Pengeluar	CUI Devices
Voltan - Rated	24VDC
Saiz thread	-
penamatan	Solder
perisai	Unshielded
Siri	-
Pakej	Tray
Suhu Operasi	-25°C ~ 85°C
Bilangan Jawatan / Kenalan	2 Conductors, 3 Contacts
pemasangan Jenis	Through Hole, Right Angle
pemasangan Ciri	-
Mengawan Negara / Kedalaman	0.386" (9.80mm)
Bahan Terbakar Rating	UL94 V-0
Tukar Negeri (s)	Single Switch, Normally Closed
penebat Warna	-

Atribut produk	Nilai atribut
Perlindungan Ingress	-
Industri Diiktiraf Mengawan Diameter	2.50mm ID (0.098"), 5.50mm OD (0.217")
termasuk	-
perumahan bahan	Polybutylene Terephthalate (PBT)
jantina	Male
ciri-ciri	Board Guide
Penarafan Semasa (AMPS)	2.5 A
Hubungi bahan - Plating	Tin
Hubungi bahan	Brass, Copper Alloy
Jenis penyambung	Jack
Bahan badan	-
Warna badan	Black
Nombor produk asas	PJ-059
Diameter sebenar	0.098" (2.50mm ID), 0.224" (5.70mm OD)

Klasifikasi Alam Sekitar & Eksport

ATRIBUT	PENERANGAN
Status RoHS	Mematuhi ROHS3
Tahap Sensitiviti Kelembapan (MSL)	1 (Unlimited)
Mencapai status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040

Bahagian dengan spesifikasi yang serupa

Tiga bahagian di sebelah kanan mempunyai spesifikasi yang sama dengan CUI Devices PJ-059B.

Atribut produk
Nombor Bahagian	PJ-059BH	PJ-065B	PJ-059A	PJ-058BH
Pengeluar	CUI Devices	CUI Devices	CUI Devices	CUI Devices
Siri	-	-	-	-
Tukar Negeri (s)	-	-	-	-
Penarafan Semasa (AMPS)	-	-	-	-
termasuk	-	-	-	-
Saiz thread	-	-	-	-
Mengawan Negara / Kedalaman	-	-	-	-
Bahan Terbakar Rating	-	-	-	-
Bahan badan	-	-	-	-
Voltan - Rated	-	-	-	-
pemasangan Ciri	-	-	-	-
Perlindungan Ingress	-	-	-	-
Warna badan	-	-	-	-
Diameter sebenar	-	-	-	-
penebat Warna	-	-	-	-
Hubungi bahan	-	-	-	-
Bilangan Jawatan / Kenalan	-	-	-	-
Suhu Operasi	-	-40°C ~ 85°C	0°C ~ 70°C	-40°C ~ 85°C
jantina	-	-	-	-
Hubungi bahan - Plating	-	-	-	-
pemasangan Jenis	-	Surface Mount	Through Hole	Surface Mount
Pakej	-	Tape & Reel (TR)	Tube	Tape & Reel (TR)
ciri-ciri	-	-	-	Simultaneous Sampling
Industri Diiktiraf Mengawan Diameter	-	-	-	-
Jenis penyambung	-	-	-	-
Nombor produk asas	-	DAC34H84	MAX500	ADS62P42
penamatan	-	-	-	-
perisai	-	-	-	-
perumahan bahan	-	-	-	-
